9001KA1 - Square D - 10 Amp Pushbutton Contact Block

10 Amp - 2 Pole - 600 Volt

Schneider Electric SKU: 9001KA1
9001KA1 - Square D 10 Amp 2 Pole 600 Volt Pushbutton Contact Block

Images are for reference only

9001KA1 - Square D - 10 Amp Pushbutton Contact Block

10 Amp - 2 Pole - 600 Volt

Schneider Electric SKU: 9001KA1
/
  • In stock and ready to ship
  • Inventory on the way
Condition
Rush shipping options calculated at checkout.

Earn 85 reward points

  • Secure transaction
  • FREE & fast shipping on orders over $49
  • CSA approved with 1 year warranty
  • 30 day returns

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - 9001KA1 - Square D - 10 Amp Pushbutton Contact Block

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

9001KA1 - Square D Pushbutton Contact Block

Square D pushbutton contact compact easy to install its a easy to use finger safe 30mm pushbutton contact contact configuration 1no-1nc and contact rating 600 vac/vdc 10 ampere Suitable for use with programmable controller.

Specifications:

  • Range of product: Harmony 9001K
  • Product or component type: Contact block with protected terminals
  • Device short name: 9001K
  • Net weight: 0.027 kg
  • Contacts type and composition: 1 C/O
  • Contact operation: Standard
  • Positive opening: Without
  • Connections - terminals: Screw clamp terminals, 1 x 0.22...2 x 2.5 mm2 conforming to IEC 60947-1
  • Tightening torque: 0.8 N.m conforming to IEC 60947-1
  • Shape of screw head: Cross slotted
  • Contacts material: Silver alloy contacts
  • Short-circuit protection: 10 A cartridge fuse conforming to IEC 60947-5-1
  • [Ith] conventional free air thermal current: 10 A
  • [Ui] rated insulation voltage: 250 V (pollution degree 3) conforming to IEC 60947-1
  • [Uimp] rated impulse withstand voltage: 2.5 kV conforming to IEC 60947-1
  • [Ie] rated operational current: 3 A at 240 V, AC-15, A600-Q600 conforming to NEMA, 0.55 A at 125 V, DC-13, A600-Q600 conforming to NEMA
  • [Icm] rated short-circuit making capacity: 12 kA at 600 V AC-15, 7200 VA, 15 kA at 480 V AC-15, 7200 VA, 30 kA at 240 V AC-15, 7200 VA, 60 kA at 120 V AC-15, 7200 VA, 0.1 kA at 600 V DC-13, 7200 VA, 0.27 kA at 250 V DC-13, 7200 VA, 0.55 kA at 125 V DC-13
  • Rated breaking capacity: 3 kA at 240 V AC-15, 720 VA, 6 kA at 120 V AC-15, 720 VA, 1.2 kA at 600 V AC-15, 720 VA, 1.5 kA at 480 V AC-15, 720 VA, 0.1 kA at 600 V DC-13, 0.27 kA at 250 V DC-13, 0.55 kA at 125 V DC-13
  • Protective treatment: TC
  • Ambient air temperature for storage: -40...70 Degree C
  • Ambient air temperature for operation: -25...70 Degree C
  • Electrical shock protection class: Class II conforming to IEC 61140
  • IP degree of protection: IP20 conforming to IEC 60529
  • Standards: EN/IEC 60947-5-1, JIS C 4520, UL 508, EN/IEC 60947-1, JIS C 852, CSA C22.2 No 14, EN/IEC 60947-5-4
  • Product certifications: NEMA, UL 508
  • Vibration resistance: 7 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
  • Shock resistance: 50 gn conforming to IEC 60068-2-27
  • Authentic Square D Product
  • Voltage Rating: 600 Volt
