CHF230 - Eaton - 30 Amp Circuit Breaker

Plug-In - 30 Amp - 2 Pole - 240 Volt

Eaton Cutler-Hammer SKU: CHF230
CHF230 - Eaton - 30 Amp Circuit Breaker
CHF230 - Eaton - 30 Amp Circuit Breaker
CHF230 - Eaton - 30 Amp Circuit Breaker
CHF230 - Eaton - 30 Amp Circuit Breaker
CHF230 - Eaton Cutler-Hammer 30 Amp 2 Pole 240 Volt Plug-In Molded Case Circuit Breaker
CHF230 - Eaton Cutler-Hammer 30 Amp 2 Pole 240 Volt Plug-In Molded Case Circuit Breaker

Images are for reference only

CHF230 - Eaton - 30 Amp Circuit Breaker

Plug-In - 30 Amp - 2 Pole - 240 Volt

Eaton Cutler-Hammer SKU: CHF230
/
  • In stock and ready to ship
  • Inventory on the way
Condition
Rush shipping options calculated at checkout.

Earn 89 reward points

  • Secure transaction
  • FREE & fast shipping on orders over $49
  • CSA approved with 1 year warranty
  • 30 day returns

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - CHF230 - Eaton - 30 Amp Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

CHF230 - Eaton Cutler-Hammer Plug-In Molded Case Circuit Breaker

Cutler Hammer CHF series double pole 30 ampere plug-in molded case circuit breaker with maximum voltage rating of 240V tripping method thermal magnetic and standard interrupting rating of 10 kiloampere at 240V complete with (LI) long-time and instantaneous trip functions with mechanical trip flag.

Specifications:

  • Product Name: Type CHF 3/4-inch Standard Circuit Breaker
  • Product Length: 3 IN
  • Product Height: 3 IN
  • Product Width: .75 IN
  • Product Weight: .28 LB
  • Certifications: UL 489
  • Catalog Notes: HACR Rated. Two-Pole 120/240V Common Trip Requires Two 3/4-Inch Spaces. With Trip Indication
  • Interrupt Rating: 10 kAIC
  • Wire Size: (1) #14-8 AWG, (2) #14-10 AWG Cu/Al
  • Used With: Type CH Loadcenters
  • Main Circuit Breaker: CH
  • Voltage Rating: 120/240V
  • Amperage Rating: 30A
  • Trip Type: Common
  • Number Of Poles: Two-pole
  • Authentic Eaton/Cutler-Hammer Product
  • Dimensions (H x W x L): 3" x 0.75" x 3"
