Product Warranty - EDH2200L - Eaton - Molded Case Circuit Breaker
All products carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic, factory new and CSA approved.
Overview
Product Specifications - EDH2200L - Eaton Molded Case Circuit Breaker
-
Part Number:
EDH2200L -
Manufacturer:
-
Family:
Series C -
Pole:
2 -
Amp
200 -
Volt:
240 -
Phase:
2
-
Category:
-
Connection:
Feed-Thru -
Type:
EDH -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
100kA@240V
Dimensions
-
Dimensions (HxWxD):
2.75" x 2.75" x 3.38"
-
Weight:
3 lbs
Standards
Product Description - EDH2200L - Eaton Molded Case Circuit Breaker
Cutler Hammer / Eaton / Westinghouse, Series C, type EDH, 2P, 2PH, 200A, 240V, 100kA@240V, high interrupting capacity, 40 degree C, feed-thru, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic, molded case circuit breakers.
