PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker

Bolt-On - 1200 Amp - 3 Pole - 600 Volt

Eaton Cutler-Hammer SKU: PDG53M1200E2MN
PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker
PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker
PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker
PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker

Images are for reference only

PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker

Bolt-On - 1200 Amp - 3 Pole - 600 Volt

Eaton Cutler-Hammer SKU: PDG53M1200E2MN
/
  • In stock and ready to ship
  • Inventory on the way
Condition
Rush shipping options calculated at checkout.

Earn 13152 reward points

  • Secure transaction
  • FREE & fast shipping on orders over $49
  • CSA approved with 1 year warranty
  • 30 day returns

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - PDG53M1200E2MN - Eaton - Molded Case Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - PDG53M1200E2MN - Eaton Molded Case Circuit Breakers

  • Part Number:

    PDG53M1200E2MN

  • Manufacturer:

    Eaton Cutler-Hammer

  • Family:

    Series G

  • Pole:

    3

  • Amp

    1200

  • Volt:

    600

  • Phase:

    3

  • Category:

    Molded Case / 3-Pole

  • Connection:

    Bolt-On

  • Type:

    PDG

  • Functions:

    LSI - Long-Time, Short-Time and Instantaneous

  • Protection:

    Solid State

  • AIC Ratings:

    65kA@480V | 35kA@600V

Dimensions

  • Dimensions (HxWxD):

    16" x 8.25" x 5.5"

  • Weight:

    47 lbs

Standards

CSA Approved logo

Product Description - PDG53M1200E2MN - Eaton Molded Case Circuit Breakers

Eaton Power Defense, Series G, type PDG, 3P, 3PH, 1200A, 600V, 100 kAIC at 240 Vac, 65 kAIC at 480 Vac, high interrupting capacity, bolt-on, complete with Digitrip RMS 310+ trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and imperial tapped line/load conductors, lugs not included, solid state electronic, molded case circuit breakers
