Name: FBN36TE080RV - General Electrics - Molded Case Circuit Breakers
Brand: GE
SKU: FBN36TE080RV
Price: 1285.99 CAD
Availability: InStock

FBN36TE080RV - General Electrics - Molded Case Circuit Breakers

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 1029 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40963430416493,"title":"New","option1":"New","option2":null,"option3":null,"sku":"FBN36TE080RV","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"FBN36TE080RV - General Electrics - Molded Case Circuit Breakers - New","public_title":"New","options":["New"],"price":128599,"weight":3175,"compare_at_price":null,"inventory_management":"shopify","barcode":"783164395228","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41953097154669,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"FBN36TE080RV_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"FBN36TE080RV - General Electrics - Molded Case Circuit Breakers - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":102899,"weight":3175,"compare_at_price":128599,"inventory_management":"shopify","barcode":"783164395228","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - FBN36TE080RV - General Electrics - Molded Case Circuit Breakers

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - FBN36TE080RV - General Electrics Molded Case Circuit Breakers

Part Number:

FBN36TE080RV
Manufacturer:

General Electric
Family:

Record Plus
Pole:

3
Amp

80
Volt:

600
Phase:

3

Category:

Molded Case Circuit Breakers / 3-Pole
Connection:

Bolt-On
Type:

FBN
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

65kA@480V

Dimensions

Dimensions (HxWxD):

8.75 x 4.5 x 4.75
Weight:

7 lb

Standards

Product Description - FBN36TE080RV - General Electrics Molded Case Circuit Breakers

FBN36TE080RV, another product from General Electric's Record Plus series, this circuit breaker shares the type FBN and FB100 frame characteristics. It features a 3P (3-phase) configuration with an 80A current rating and a high interrupting capacity of 65kA@480V. The Bolt-On design ensures easy installation, and the package includes Long-Time (LI) and Instantaneous trip functions, load side lug terminals, panel connections, and fixed Thermal Magnetic features.

FBN36TE080RV - General Electrics - Molded Case Circuit Breakers

Bolt-On - 80 Amp - 3 Pole - 600 V
