Name: TFJ236200WL - General Electrics - Molded Case Circuit Breakers
Brand: GE
SKU: TFJ236200WL
Price: 5714.99 CAD
Availability: InStock

TFJ236200WL - General Electrics - Molded Case Circuit Breakers

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 4001 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40963437789293,"title":"New","option1":"New","option2":null,"option3":null,"sku":"TFJ236200WL","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"TFJ236200WL - General Electrics - Molded Case Circuit Breakers - New","public_title":"New","options":["New"],"price":571499,"weight":6804,"compare_at_price":null,"inventory_management":"shopify","barcode":"78316400777","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42575251767405,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"TFJ236200WL_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"TFJ236200WL - General Electrics - Molded Case Circuit Breakers - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":400099,"weight":6804,"compare_at_price":null,"inventory_management":"shopify","barcode":"78316400777","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - TFJ236200WL - General Electrics - Molded Case Circuit Breakers

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - TFJ236200WL - General Electrics Molded Case Circuit Breakers

Part Number:

TFJ236200WL
Manufacturer:

General Electric
Family:

F225 Line
Pole:

3
Amp

200
Volt:

600
Phase:

3

Category:

Molded Case Circuit Breakers / 3-Pole
Connection:

Feed-Thru
Type:

TFJ
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

22kA@480V

Dimensions

Dimensions (HxWxD):

3.8 x 4.1 x 10.1
Weight:

15 lb

Standards

Product Description - TFJ236200WL - General Electrics Molded Case Circuit Breakers

General Electric's TFJ236200WL, belonging to the F225 Line, is a robust 3P, 200A molded case circuit breaker designed for 600V systems. With a standard interrupting capacity of 22kA@480V, this breaker is complete with both line and load side lug terminals. Its non-interchangeable trip unit enhances safety, making it suitable for reverse feed applications. Operating at 40Ã‚ÂºC, it features a Feed-Thru design and utilizes thermal magnetic technology for reliable circuit protection.

TFJ236200WL - General Electrics - Molded Case Circuit Breakers

Feed-Thru - 200 Amp - 3 Pole - 600 V
