Name: HED43B045 - Siemens - Molded Case Circuit Breaker
Brand: Siemens/ITE
SKU: HED43B045
Price: 1109.99 CAD
Availability: InStock

HED43B045 - Siemens 45 Amp 3 Pole 480 Volt Bolt-On Molded Case Circuit Breaker

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 777 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40513638432877,"title":"New","option1":"New","option2":null,"option3":null,"sku":"HED43B045","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"HED43B045 - Siemens - Molded Case Circuit Breaker - New","public_title":"New","options":["New"],"price":110999,"weight":1814,"compare_at_price":null,"inventory_management":"shopify","barcode":"783643210158","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42572246909037,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"HED43B045_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"HED43B045 - Siemens - Molded Case Circuit Breaker - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":77699,"weight":1814,"compare_at_price":null,"inventory_management":"shopify","barcode":"783643210158","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - HED43B045 - Siemens - Molded Case Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - HED43B045 - Siemens Molded Case Circuit Breaker

Part Number:

HED43B045
Manufacturer:

Siemens / ITE
Family:

Sentron Series
Pole:

3
Amp

45
Volt:

480
Phase:

3

Category:

Molded Case / 3-Pole
Connection:

Bolt-On
Type:

HED
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

42kA@480V

Dimensions

Dimensions (HxWxD):

6.35" x 3" x 4.56"

Weight:

0.3 lbs

Standards

Product Description - HED43B045 - Siemens Molded Case Circuit Breaker

Siemens, Sentron Series, type HED, 3P, 3PH, 45A ,480V, 42kA@480V, high interrupting capacity, 40 degree C, bolt-on, complete with load side lug terminals, thermal magnetic molded case circuit breakers.

Documentation

Catalogue

Installation Instructions

Data Sheet
