QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker

Bolt-On - 100 Amp - 2 Pole - 240 Volt

Schneider Electric SKU: QOB2100VH
QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker
QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker
QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker
QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker

Images are for reference only

QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker

Bolt-On - 100 Amp - 2 Pole - 240 Volt

Schneider Electric SKU: QOB2100VH
Regular price $290.99 CAD
/
  • In stock and ready to ship
  • Inventory on the way
Condition
Rush shipping options calculated at checkout.
  • Secure transaction
  • FREE & fast shipping on orders over $49
  • CSA approved with 1 year warranty
  • 30 day returns

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - QOB2100VH - Square D - 100 Amp 22kA Circuit Breaker

All products carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic, factory new and CSA approved.

QOB2100VH - Square D Bolt-On 100 Amp Breaker

Square D bolt-on circuit breaker has a voltage rating of 120/240 Volts current rating of 100 Amps and interrupting rating of 22 kilo-Amps. The 2-Pole thermal magnetic circuit breaker features a lug terminal and accommodates aluminum/copper wire size of 4 - 300 AWG.

Specifications:

  • Product: Miniature circuit-breaker
  • Range: QO
  • Line Rated Current: 100 A
  • System Voltage: 120 V AC, 120/240 V AC, 240 V AC
  • Mounting Type: Bolt-on
  • Number of Poles: 2P
  • Circuit Breaker Type: Standard
  • Ratings: HACR rated
  • Electrical Connection: Box lugs
  • Inturrupt Rating: 22 kA at: 120/240 V AC 50/60 Hz, 22 kA at: 240 V AC 50/60 Hz, 22 kA at: 120 V AC 50/60 Hz
  • Number of Panel Spaces: 2
  • Wire Size: AWG 4...AWG 2/0 (copper or aluminium)
  • Certifications: CSA, UL listed
  • Ambient Rating: 104 Degree F (40 Degree C)
  • Authentic Square D Product
  • Dimensions (H x W x L): 3.5" x 1.5" x 2.91"

Alt model: q0b2100vh
