Product Warranty - LAL26400MB - Square D - Molded Case Circuit Breakers

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - LAL26400MB - Square D Molded Case Circuit Breakers

Part Number:

LAL26400MB
Manufacturer:

Schneider Electric / Square D
Family:

LAL Series
Pole:

2
Amp:

400
Volt:

600
Phase:

1

Category:

Molded Case Breakers / 2-Pole
Connection:

Feed-Thru
Type:

L Frame
Functions:

NGC
Protection:

Thermal Magnetic
AIC Ratings:

30kA@480V

Dimensions

Dimensions (HxWxD):

11 x 6 x 5.84
Weight:

14.5 lbs

Standards

Product Description - LAL26400MB - Square D Molded Case Circuit Breakers

Square D LA molded case circuit breakers provide thermal magnetic protection. Their primary function is automatic opening of a circuit under overload or short circuit conditions or manual opening. LA circuit breakers contain thermal (overload) and magnetic (short circuit) sensing elements in each pole. Push-to-Trip allows the circuit breaker to be manually tripped without exposure to live parts. This Square D LA molded case circuit breaker is a 2 pole unit mount breaker, 400A and 600VAC, with lugs. The thermal magnetic circuit breaker has an interrupting rating of 22kA for 600VAC and 10kA for 250VDC. The circuit breaker MB suffix indicates a shorter handle so that a panel door can close. LA breakers are UL 489, CSA, IEC certified.

LAL26400MB - Square D - Molded Case Circuit Breakers

Feed-Thru - 400 Amp - 2 Pole - 600 Volt
