Name: LAL36400MB - Square D - Molded Case Circuit Breaker
Brand: Schneider Electric
SKU: LAL36400MB_recon
Price: 5548.99 CAD
Availability: OutOfStock

LAL36400MB - Square D 400 Amp 3 Pole 600 Volt Molded Case Circuit Breaker

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 3885 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40513538883693,"title":"New","option1":"New","option2":null,"option3":null,"sku":"LAL36400MB","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"LAL36400MB - Square D - Molded Case Circuit Breaker - New","public_title":"New","options":["New"],"price":554899,"weight":8618,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901005513","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42575214477421,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"LAL36400MB_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LAL36400MB - Square D - Molded Case Circuit Breaker - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":388499,"weight":8618,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901005513","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - LAL36400MB - Square D - Molded Case Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - LAL36400MB - Square D Powerpact Circuit Breaker

Part Number:

LAL36400MB
Manufacturer:

Schneider Electric / Square D
Family:

LAL Series
Pole:

3
Amp

400
Volt:

600
Phase:

3

Category:

Molded Case / 3-Pole
Connection:

Feed-Thru
Type:

LAL
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

30kA@480V

Dimensions

Dimensions (HxWxD):

11" x 6" x 5.84"

Standards

Additional Details

Frame Type:

J-Frame
Trip Unit Technology:

Thermal-magnetic
Line Rated Current:

400 Amp
Mounting Mode:

Unit Mount

Electrical Connection:

Lugs line / Lugs load
Magnetic Hold Current:

2000 Amp

Product Description - LAL36400MB - Square D Powerpact Circuit Breaker

Square D, LAL Series, type LAL, short handle, main breaker, 3P, 3PH, 400A, 600V, 30kA@480V, standard interrupting capacity, feed-thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals.

Documentation

Catalogue

Technical Specifications

Installation Instructions

LAL36400MB - Square D - Molded Case Circuit Breaker

Feed-Thru - 600 Amp - 3 Pole - 600 Volt

LAL36400MB - Square D - Molded Case Circuit Breaker
