Name: QDA32080 - Square D - Molded Case Circuit Breaker
Brand: Schneider Electric
SKU: QDA32080
Price: 2279.99 CAD
Availability: InStock

QDA32080 - Square D 80 Amp 3 Pole 240 Volt Molded Case Circuit Breaker

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 1596 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40513539244141,"title":"New","option1":"New","option2":null,"option3":null,"sku":"QDA32080","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"QDA32080 - Square D - Molded Case Circuit Breaker - New","public_title":"New","options":["New"],"price":227999,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901468721","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42575214674029,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"QDA32080_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"QDA32080 - Square D - Molded Case Circuit Breaker - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":159599,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901468721","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - QDA32080 - Square D - Molded Case Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - QDA32080 - Square D I-Line Circuit Breaker

Part Number:

QDA32080
Manufacturer:

Schneider Electric / Square D
Family:

I-Line
Pole:

3
Amp

80
Volt:

240
Phase:

3

Category:

Molded Case / 3-Pole
Connection:

I-Line Style Plug-In
Type:

QDA
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

25kA@240V

Dimensions

Dimensions (HxWxD):

6.47" x 4.5" x 3.93"

Weight:

4.9 lbs

Standards

Additional Details

Frame Type:

Q-Frame
Trip Unit Technology:

Thermal-magnetic
Line Rated Current:

80 Amp
Mounting Mode:

I-Line bracket

Breaking Capacity Code:

D
Electrical Connection:

I-Line connection line/Lugs load
Magnetic Hold Current:

1000 Amp
Continuous Current Rating:

80%
Control Type:

Operating handle

Product Description - QDA32080 - Square D I-Line Circuit Breaker

Square D, I-Line, type QDA, 3P, ABC phase connection, 3PH, 80A, 240V, 25kA@240V, UL listed, standard interrupting capacity, i-line style plug-in, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, thermal magnetic.

Documentation

Catalogue

Technical Specifications

Installation Instructions

QDA32080 - Square D - Molded Case Circuit Breaker

I-Line Plug-In - 80 Amp - 3 Pole - 240 Volt
