Name: QGL32225 - Square D - Molded Case Circuit Breakers
Brand: Schneider Electric
SKU: QGL32225
Price: 2346.99 CAD
Availability: InStock

QGL32225 - Square D 225 Amp 3 Pole 240 Volt Molded Case Circuit Breaker

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Earn 1643 reward points

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40513559199853,"title":"New","option1":"New","option2":null,"option3":null,"sku":"QGL32225","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"QGL32225 - Square D - Molded Case Circuit Breakers - New","public_title":"New","options":["New"],"price":234699,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901603559","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42575202615405,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"QGL32225_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"QGL32225 - Square D - Molded Case Circuit Breakers - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":164299,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901603559","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - QGL32225 - Square D - Molded Case Circuit Breakers

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - QGL32225 - Square D Molded Case Circuit Breakers

Part Number:

QGL32225
Manufacturer:
Schneider Electric / Square D
Family:

Powerpact
Pole:

3
Amp

225
Volt:

240
Phase:

3

Category:

Molded Case / 3-Pole
Connection:

Feed-Thru
Type:

QGL
Functions:

LI - Long-Time and Instantaneous
Protection:

Thermal Magnetic
AIC Ratings:

65kA@240V

Dimensions

Dimensions (HxWxD):

6.47" x 4.5" x 3.93"

Weight:

4 lbs

Standards

Additional Details

Trip Unit Technology:

Thermal-magnetic
Line Rated Current:

225 Amp
Mounting Mode:

Unit mount lug

Breaking Capacity Code

G
Electrical Connection:

Lugs load / Lugs line
Magnetic Hold Current:

1200 Amp
Continuous Current Rating

80%
Control Type:

Operating handle

Product Description - QGL32225 - Square D Molded Case Circuit Breakers

Schneider Electric / Square D, Powerpact, type QGL, 3P, 3PH, 225A, 240V, 65kA@240V, high interrupting capacity, complete with non-interchangeable trip, and line & load side lug terminals, thermal magnetic

Documentation

Catalogue

Installation Instructions

Technical Specifications

QGL32225 - Square D - Molded Case Circuit Breakers

Feed Thru - 225 Amp - 3 Pole - 240 Volt

QGL32225 - Square D - Molded Case Circuit Breakers
